Featured 95Power manuals
95Power UWA-02 Antenna Datasheet
The UWA-02 antenna is designed for integration into DW1000‑based tags or anchor designs and works with 95Power's DW1000 UWB transceiver, offering a low‑cost, high‑efficiency, compact solution with high fidelity and low group‑delay variation.
Key specifications include a 3 GHz‑8 GHz operating range, maximum gain of 2.2 dB at 4 GHz and 3.3 dB at 6.5 GHz, 50 Ω input impedance, SMA‑male connector, and performance figures such as return loss, antenna efficiency, group‑delay variation (<±100 ps) and fidelity factor (>90%). This manual is written in Chinese.
Covers: General Description · Dimension · Operating Conditions · Simulation Results · Radiation Patterns · Return Loss
95Power VDB1506 Safety Helmet Tag Datasheet
The VDB1506 safety helmet tag from 95Power is a low‑power BLE device based on the NRF52832 chip, designed for indoor positioning and presence detection in construction sites, factories and mines. It features an accelerometer, SOS button, vibration alert, magnetic charging, a 1000 mAh rechargeable battery and IP65 waterproof protection.
The datasheet provides product parameters, operating instructions (power on, SOS, power off, charging) and installation methods (drilling or 3M adhesive) together with contact information for sales and technical support. This manual is written in Chinese.
Covers: Product Introduction · Working Parameters · User Manual · Product Setup · Contact Information
95Power VDU4505 Active Positioning System User Manual
The VDU4505 UWBTWR active positioning system consists of a UWB ranging base station and tags (helmet, chest, etc.) that enable precise indoor location tracking. The system can be built using the VDU2506 base station or the SKU620 core module, and tags are powered by rechargeable batteries.
The manual guides users through hardware installation requirements, tag ID acquisition via Bluetooth, software configuration steps, and how to start coordinate conversion and view real‑time positioning results. Contact information for 95Power support is provided at the end. This manual is written in Chinese.
Covers: Overview · System Kit · Hardware Preparation · Positioning System Operation Flow · Positioning Effect Demonstration · Contact Information
Latest 95Power manuals
95Power UWA-02 Antenna Datasheet
Datasheet 11 pages · 465 KB · ZHThe 95Power UWA-02 antenna datasheet provides dimensions, operating frequency range, gain, impedance, and performance metrics such as return loss and group…
95Power VDB1506 Safety Helmet Tag Datasheet
Datasheet 10 pages · 566 KB · ZHTechnical specifications and usage instructions for the 95Power VDB1506 safety helmet tag.
95Power VDU4505 Active Positioning System User Manual
User Manual 12 pages · 1.2 MB · ZHThis manual explains the setup, hardware preparation, operation flow, and demonstration of the VDU4505 UWBTWR active positioning system.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in 95Power manuals
What frequency range does the UWA-02 antenna operate in?
It operates from 3 GHz to 8 GHz.
What is the maximum gain of the UWA-02 antenna?
The maximum gain is 2.2 dB at 4 GHz and 3.3 dB at 6.5 GHz.
How do I power on the VDB1506 tag?
Long‑press the tag button until the red LED lights and the motor vibrates; release the button and the red LED stays on for about 3 seconds then turns off, indicating successful startup.
How can I trigger an SOS alert?
While the tag is operating, press and hold the button for more than 3 seconds; the blue LED will flash briefly to confirm the SOS has been sent.
How many tags are required for optimal calibration?
At least four tags should be installed to achieve the best calibration results.
How can I obtain the Tag ID?
After the tag starts, use the nRFConnect app to scan Bluetooth devices; devices whose name starts with "Tg" provide the Tag ID.
