The DODGE D-Series motor brakes are manufactured to NEMA standards for mounting to C-face and double shafted motors. They operate as spring-set, electrically released power-off brakes to provide a holding or parking action.
This manual covers the complete installation process for the MN413 motor brake, including pre‑installation checks, mounting procedures for single‑C‑face and double‑C‑face models, and required torque values. Detailed electrical connection guidelines, wiring diagrams, and safety warnings are provided to ensure proper integration with the motor and control system.
Additional sections describe maintenance adjustments, wear‑indicator checks, rectifier testing, and a troubleshooting guide with common symptoms and corrective actions. The document is intended for qualified personnel responsible for installing and servicing the brake.
